Bigboy Technologies use industry leader Samsung DDR5 modules.
DDR5 was developed to meet the growing IT needs due to the growing amount of data. Increased speed, improved capacity and stronger security features are combined in DDR5 to improve overall system performance. Offering high power savings with Samsung memory technologies, DDR5 provides environmentally friendly solutions.
Compliant with JEDEC international standards, Bigboy next-generation DDR5 memory modules are manufactured using high-quality DRAM chips that have undergone rigorous testing. Bigboy DDR5 4800 memory features two independent 32-bit channels capable of speeds up to 4,800 MT/s. The low operating voltage of 1.1 V and PMIC effectively reduce signal interruption while lowering PC power consumption. On-die ECC automatically detects and corrects data errors, improving data integrity and system stability.
Products : B48SC40D5-8, B48SC40D5-16 , B48SC40D5-32
- Capacity : 8GB, 16GB, 32GB
- Speed : DDR5-4800, PC5-38400
- Latency : CL=40, tRCD=40, tRP=40
- Organization : (1G x 16) x 4 (8GB), (2G x 8) x 8 (16GB), (2G x 8) x 16 (32GB)
- Rank : 8GB – Single Rank 1Rx16, 16GB – Single Rank 1R x 8, 32GB – Dual Rank 2Rx8
- Number of Pin : 262
- Voltage : 1,1V
- Warranty : Limited Lifetime
- Ürün Kodu : B48SC40D5-8 Datasheet, B48SC40D5-16 Datasheet, B48SC40D5-32 Datasheet
